This plastic thru-hull mount transducer performs well at high speeds.

An excellent choice for fiberglass and metal hulls, this 8-pin 600 W transducer has a depth of 800 to 1,200 ft; an operating frequency of 50 to 200 kHz; a beamwidth of 45 to 12 degrees; and a 0 to 7 degree deadrise.

Transducer kit comes with installation instructions. Follow the instructions carefully to avoid damaging your boat.

Specifications

Accommodates 44 mm (1.7″) diameter dual frequency 50/200 kHz piezoceramic
50/200 kHz frequency provides both good resolution and deep water performance
Good high speed performance when mounted well aft
Minimal drag with only 5 mm (3/16″) extending outside hull
Shielded piezoceramic element for noise free echosounder display
Rubber washer allows tightening of hull nut to irregular surfaces.
Installation requires 51 mm (2″) diameter hole
Standard cable length: 9 m (30′)
Weight: 0.6kg (1.3lb.)
Rated RMS Power: 600W
