Features

Full compliance with IEC62287-1, IEC62287-2, Class B+ AIS standards and AIS SART standards

ONWA AIS Encrypted Technology

Outputs AIS and GPS data on RS232 NMEA ports to other navigational equipment on board

Can Transmit and Receive AIS Data of targets around your boat (with suitable VHF Antenna)

The AIS Data such as MMSI, call Sign, boat name etc. Can be configured with the included windows compatible software

AIS Characteristics

Frequency Rate:156.025 MHz~162.025 MHz

Access Scheme: SOTDMA

Channel Bandwidth:25 kHz

Modulation: GMSK

Data Rate:9,600 bps

Number of AIS Transmitter:1

Number of AIS Receiver:2

AIS Channel 1:CH 87B (161.975 MHz)

AIS Channel 2:CH 88B (162.025 MHz)

Tx Power Output:>5 Watt (37 dBm ± 1.5 dB)

RX Sensitivity:<-123dBm @ 20% PER

RX Message Format: AIS Class A and B messages

Comply Standard: IEC-62287 IEC 62287-2 Ed. 2.0:2017

NMEA

NMEA Sentence Supported: VDM, VDO, RMC, GSV, GGA, GSA

GPS Receiver (AIS Internal)

IEC61108-1 compliant

Physical Dimension;  207mm (length) x 155.8mm (Width) x 50mm (Height)

Weight0.8kg

Power Supply : 10 ~ 35 VDC; 0.35A nominal, 2A peak

Environment: Temperature-25°C to +55°C

Electrical Interface : RS232 38.4kbaud bi-directional

What’s in the box for KS-200A Only:

KS-200A x 1

Power/Data Cable x 1,

User Manual x 1.

What’s in the box for KS-200A Full Set:

KS-200A x 1,

Power/Data Cable x 1,

KA-159 1.2m VHF Antenna with 10m Cable x 1,

KA-07 GPS Antenna with 10m Cable x 1,

User Manual x 1.

One year warranty.
